Место происхождения: | Шандунская провинция, Китай |
---|---|
Фирменное наименование: | SH |
Сертификация: | ISO9001,CE |
Номер модели: | SHJM-400, SHJM-650, SHJM-800, SHJM-1000 и т. Д. |
Количество мин заказа: | 1 набор |
Цена: | US $5,300-13,950 / Set |
Упаковывая детали: | загрузка упаковки или контейнера рамки утюга |
Время доставки: | в течение 15 дней |
Условия оплаты: | T/T, Western Union |
Поставка способности: | 1000 комплектов/год |
Имя: | точность resaw ленточная пила | Состояние: | Новый |
---|---|---|---|
Тип: | Полоса перепродажа | Основная мощность двигателя: | 15kw, 18.5kw, 22kw, 30kw |
Кормление двигателя: | 0,75 кВт, 1,5 кВт | Диаметр пилового колеса: | 600mm, 700mm |
Максимальная ширина пилы: | 1000 мм | Максимум Высота обработки: | 110 мм |
Скорость кормления: | Инвертор, скорость регулируемая | Гарантия:: | 1 год |
Послепродажная служба предоставлена: | Онлайн поддержка, видео- служба технической поддержки, поручая и тренируя | ||
Выделить: | horizontal band sawmill for wood cutting,precision band resaw machine,industrial bottom cutting sawmill |
For high-volume woodworking operations, achieving flawless, consistent cuts isn't just a goal—it's a necessity for profitability. An industrial precision resaw bandsaw is engineered to deliver exactly that: unparalleled accuracy and efficiency in every cut. This machine transforms raw lumber into high-value products by maximizing yield and ensuring a superior finish, directly boosting your bottom line through reduced waste and increased output.
Unmatched Cutting Accuracy & Consistency
Benefit: Produce glue-ready laminates and perfectly dimensioned lumber with exceptional smoothness, minimizing the need for secondary planing or sanding.
Features Behind the Benefit: A sophisticated fence system ensures precise workpiece positioning, while computer-balanced wheels and ultra-rigid construction eliminate vibration for dead-straight cuts.
Industrial-Grade Construction for Demanding Environments
Benefit: Experience rock-solid stability and durability that stands up to the rigors of continuous production, ensuring long-term reliability and minimal downtime.
Features Behind the Benefit: Built with heavy-duty components like solid cast-iron wheels, robust trunnions, and a large, stable cast-iron table that forms an unshakable foundation.
Model | SHJM-400 | SHJM-650 | SHJM-800 | SHJM-1000 |
Saw wheel diameter | 600MM | 700MM | 700MM | 700MM |
Max. processing width | 400MM | 650MM | 800MM | 1000MM |
Max. processing height | 110MM | 110MM | 110MM | 110MM |
Sawn min.thickness | 2MM | 2MM | 2MM | 2MM |
Feeding speed | 0.1-30m/min | 0.1-30m/min | 0.1-30m/min | 0.1-30m/min |
Main motor power | 15KW | 18.5KW | 22KW | 30KW |
Feeding motor power | 0.75KW | 0.75KW | 1.5KW | 1.5KW |
Sawn sizes setting | CNC digital | CNC digital | CNC digital | CNC digital |
Machine weight | 1850kgs | 2550kgs | 2750kgs | 3150kgs |
Precision Slice Horizontal Band Sawmill
Horizontal Resaw Band Saw Mills | |||
Model | SH350 | SH650 | SH800 |
Saw Wheel Diameter | 710 mm | 710 mm | 710 mm |
Maximum Cutting Width | 350 mm | 650 mm | 800 mm |
Maximum working Wood Height | 200 mm | 220 mm | 220 mm |
Max Sawing Height
|
100 mm | 110 mm | 110 mm |
Min Sawing Thickness
|
2 mm | 2mm | 2mm |
Feeding speed | Variable Frequency Adjusted Speed | ||
Main Electric Motor Power | 15 KW | 18.5 KW | 18.5KW |
Up/down motor | 0.37kw | 0.37kw | 0.37kw |
Feeding motor | 1.1kw | 1.1kw | 1.5kw |
Machine Weight | 1000 KG | 1200 KG | 1400 KG |
Is a Precision Resaw Bandsaw Right for You?
This machine is purpose-built for industrial production settings, cabinet shops, and specialized mills focused on high-volume, precision work. If your operations involve frequently breaking down thick stock or require the ability to produce thin, consistent slices of wood with a flawless finish, a precision resaw is an indispensable asset.
